WEDA60460 Atlas Copco Weda 40N 460/3/60 5 HP, 3" or 4" discharge, 55 lbs.
WEDA60460 Atlas Copco Weda 40N 460/3/60 5 HP, 3" or 4" discharge, 55 lbs.
Shipping calculated at checkout
WEDA60460 Atlas Copco Weda 40N 460/3/60 5 HP, 3" or 4" discharge, 55 lbs.
Portable electric submersible pump for dewatering of construction sites,
mines, flooded areas etc. Designed for handling liquid with abrasive
particles. Prot class IP68
Motor Protection
Thermal switch in each winding (+266 degree F)
Cable
Oil and wear resistant rubber cable 65ft 4 x AWG 16
Shaft Seal
Double seals with oil compartment
Primary seal: Silicon carbide against silicon carbide. Secondary seal: Lip seal against wear
sleeve.
Bearings
Single-row ball bearing with C3 clearance.
Materials
Castings: Aluminium
Outer-casing: Aluminium
Shaft: Stainless steel
Fasteners: Stainless steel
Impeller: Cr-alloyed white cast iron
Wear parts: Nitrile rubber
Discharge connection
3” NPT std, opt 4”, hose or BSP
Accessories
• Low suction collar
• Float switch
• Zinc anodes
• Epoxy Coating
• Stainless steel strainer
• Quick coupling type 1, 2.5”
