1" MNPT x FNPT 304 SS Street 90 Degree Elbow
$37.70
Sale price
$37.70
Regular price
Shipping calculated at checkout
The ZORO SELECT 2UA71 is a stainless steel pipe fitting designed as a 90 Degree Street Elbow. It connects two pipes at a right angle, forming a 304 stainless steel material rated for a maximum working pressure of 3000 psi at 100°F, compatible with 1-inch MNPT x FNPT threaded connections. The fitting has a male connection on Side A with a 1-inch nominal size and 1-inch NPT threaded ends, and a female connection on Side B, also 1-inch in size with 1-inch NPT threads. It conforms to ASTM A182 standards and ASME B16.11 specifications. Dimensions and thread standards conform to ASTM A182 and ASME B16.11 standards.
Key Features:
- - Material: 304 Stainless Steel
- - Pressure Rating: Class 3000; Max pressure 3000 psi@100°F; Max steam pressure 2500 psi@350°F
- - Connection Type: MNPT x FNPT with threaded ends
- - Gender: Side A Male; Side B Female
- - Pipe Size: Both sides 1 inch
- - Shape: 90 Degree Street Elbow for right-angle pipe turns
- - Standards: ASTM A182; ASME B16.11
- Ship Pack Height: 2.4
- Ship Pack Length: 3.8
- Ship Pack Width: 2.8
