5314 - Angular Contact Ball Bearing
5314 - Angular Contact Ball Bearing
Shipping calculated at checkout
Premium Angular Contact Ball Bearing Design
The 5000 series angular contact ball bearings are double-row bearings designed to support combined radial and axial loads. Their precision construction provides reliable performance, high load capacity, and smooth operation in a wide range of industrial and mechanical applications.
| Part Number | 5314 |
|---|---|
| Inner Diameter (ID) | 2.756 in | 70 mm |
| Outer Diameter (OD) | 5.906 in | 150 mm |
| Width | 2.5 in | 63.5 mm |
Cross Reference (Interchangeable Numbers)
3314, 3314A, 3314B, 3314J, 3314-2RS, 5314A, 5314A2RS, 5314A2Z, 5314C, 5314CFF, 5314CZZ5314A2RS, 5314E, 5314M, 5314W, 70BE33, 15BBNON, 3056314
Applications
- Electric motors
- Pumps and compressors
- Gearboxes and transmissions
- Machine tool spindles
- General industrial machinery
